現場のヒーロー 配管工 七つ道具

Features 現場のヒーロー 配管工 七つ道具

Also used by professional plumbers!Easy calculation app "Seven Plumber Tools" by On-site Hero■ What are the seven plumber tools?"Seven Plumber Tools" is an application for plumbers who can easily calculate the dimensions of plumbers with a smartphone.In addition to dimensional calculation, it also has a function that allows you to find out which piping joint or flange you need with a single tap.It is also used by professional craftsmen with more than 30 years of plumbering experience.■ Recommended users・ I want to eliminate manual calculations and eliminate mistakes・ I want to quickly find the main materials used in piping・ I want to confirm accurate information on materials・ Im not good at complicated apps・ I want to improve my career as a plumber■ Reasons for choosing seven plumber tools1.
Full of features not found in other apps2.
Easy-to-understand screen3.
Frequent improvement according to users request■ 7 functions1.
Piping cutting dimension calculationBy inputting the core dimension of the fitting from the fitting in the drawing, the cutting dimension of the pipe can be calculated by subtracting the dimension of the fitting.2.
Piping joint quick reference tableBy simply selecting the size of the pipe fitting, it is possible to display the main fitting and U-bolt required at the time of manufacture, the wall thickness of the pipe, the capacity inside the pipe, and the weight.3.
Flange quick reference tableBy simply selecting the flange size, you can display the flange size, number of bolt holes, bolt size, spanner size, and hydraulic pressure for each flange 0 ring size.4.
Cumulative dimensionsBy inputting the dimensions of the pillars from the pillars of the building, the cumulative dimensions from the reference point can be calculated, so mistakes when constructing long pipes can be prevented.5.
Trigonometric functionYou can calculate the length of the other two sides just by entering the angle and the length of one side.
It can also be calculated under other conditions.6.
Piping materialBy simply selecting the type of piping material, you can display the common name, standard number, location of use, and general connection method.7.
Symbol tableWelding symbols, etc.
on the drawing can be displayed in a list.
